# Pieces Description
16 2x M6 screw (3,5cm) (incl. Washer and Nut)
17 2x Plastic shims
18 1x M8 screw (5,5cm) (incl. Washer and Nut)
19 1x M6 screw (2,3cm) (incl. Washer and Nut)
Assembly
Step 1
Remove the two black transport protectors
from the frame (2)
Step 2
Fit the reflector mounting (8) to the frame (2), as shown. Fit
the two red reflectors (6) to face the rear, and the two white
reflectors (7) to face the front.
After fitting the reflector mountings (8) to the frame (2), push
each reflector (6+7) into its respective mounting (8).
