1. Technical Data

Modell
Input Voltage
Input Signal
Power output
Ambient temperature
Dimensions
Net-weight

2. Specifications

1. Power supply by a separate power supply
2. PWM-signal as Input
3. Boosted PWM signal as output

3. Dimensions and Connections

DC Power supply
PWM signal input & output
MBN GmbH, Balthasar-Schaller-Str. 3, 86316 Friedberg - Germany
PROLED POWER BOOSTER 24 A 1-CHANNEL
12 – 24 VDC
PWM-signal
288 / 576 W (12 / 24 VDC)
-10°C – 45°C
150 mm × 55 mm x 33 mm (LxBxT)
230 g
IP 20
BOOSTER 24 A 1-KANAL
www.proled.com
Users manual / Bedienungsanleitung
150 mm
1 channel output
Replacable fuse
LED indicator
