Replacing transmitter Keypad

Depending on which control mode is selected, the keypad of the transmitter
needs to be changed:
• Remove the philips head screw and open the transmitter
• Replace the Keypad in the top part of the transmitter housing
• Reassemble in reverse order
Pairing the handheld remote to the PLP-REM
All handheld transmitters are already paired in the factory and ready to use. In
case a problem arises, the pairing process can be done as below:
1) Press the pairing button on the circuit board, inside the PLP-REM
---> The BLUE LED will start to blink
2) Within 25 seconds, push any button on the handheld transmitter.
---> If the remote is paired correctly, the BLUE LED will flash slowly for 5 times
---> UNPAIRING:
Pairing Indicator LED
(blue)
Downloaded from www.Manualslib.com
See RESET procedure: page 16
manuals search engine
Keypad for
PLC mode
Keypad for
ON/OFF mode
DuraLink
Pairing button
