System Overview

Hard Drive Installations
Downloaded from www.Manualslib.com
Quick Installation Guide
(Front)
Power button
HDD LEDs
1. Push the silver button
to release the HDD tray
3. Place the HDD on the tray and
secure the HDD with the screws at the
bottom (as illustrated)
manuals search engine
(Rear)
HDD Tray
USB slot
Power Jack
2. Pull out the HDD tray
4. Push the tray back in the unit
and press down the black bar
to secure the tray
Page 3
Smart Fan
Micro
security slot
Gigabit Reset /Restart
Ethernet
