Where to install the product
The radar is intended for monitoring open areas. Any solid object (such as a tree or a bush) in the
coverage area will create a blind spot (radar shadow) behind it.
Install the radar on a pole, or on a spot on a wall where there are no other objects or installations
next to it. Objects that reflect radio waves close to the radar affects the performance.
To be able to correctly identify movement in the coverage area, the radar needs to be installed
on a stable mount. Do not install the radar on a swaying pole.
Metal objects in the field of view causes reflections that affects the performance.
Avoid aiming the radar towards another radar.
If more than two radars are mounted close together they may interfere with each other. To avoid
interference from other AXIS D2110-VE Security Radars, see Install multiple radars on page 10.

Detection range

For optimal performance, install the radar 3.5 m (11 ft) above ground.
Note
• If you install the radar at a different height, enter the actual mounting height in the
product's web pages when you calibrate the radar.
• The detection range is affected by the scene.
• The detection range is affected by neighboring radars.
• The detection range is affected by the object type.
The detection range was measured under these conditions:
• The range was measured along the ground.
• The object was a 170 cm (5 ft 7 in) tall person.
• The person was walking straight in front of the radar.
• The values are measured when the person enters the detection zone.
• The radar sensitivity was set to Medium.
Mounting height
2.5 m
(8.2 ft)
3.5 m
(11 ft)
AXIS D2110-VE Security Radar
0° tilt
3.0–60 m
(9.8–197 ft)
3.0–60 m
(9.8–197 ft)
9
10° tilt
Not recommended
Not recommended
20° tilt
Not recommended
Not recommended
