Example 2
This example shows 4 SC5000M Prime units with their Link ports connected to Link Ports 1–4 of a Denon
DJ X1800 Prime mixer. All 4 units are networked through the mixer.
Note: If you will use a different mixer with this setup, connect the Link ports all 4 SC5000M Prime units to an
Ethernet hub instead of to the mixer.
SC5000M Prime
(rear panel)
Power
outlet
SC5000M
Prime
(rear panel)
Power
outlet
RF Warning: This is a mobile device. Maintain a distance of at least 8 inches / 20 centimeters of separation between the transmitter's
radiating structure(s) and your body or other people nearby.
6
USB
drive
X1800 Prime mixer
(rear panel)
SD card
USB
drive
SC5000M Prime
(front panel)
USB drive
SC5000M Prime
(rear panel)
Power
outlet
SC5000M
Prime
(rear panel)
Power
outlet
