INtRODUctION
Share your HDMI sources with a single HD monitor. This 3x1 HDMI
Switch allows you to switch between 3 HDMI sources (set top box,
DVD players, video game stations, etc.) and your HD monitor easily.
This switch passes both digital and audio signals through the HDMI
ports and supports HDMI resolution up to 4Kx2K! It is powered from
HDMI cable and ensures high-quality signal transmission as well.
FEAtURES
1. Plug and Play, no software driver is needed;
2. Transfer high definition video and digital audio via one HDMI Cable;
3. HDMI resolution up to 4kx2K and UXVGA resolution up to 1920 x
1200.
PAckAgE cONtENtS
• 3x1 HDMI Switch *1
• Remote control *1
• User manual *1
INtERFAcE SPEcIFIcAtIONS
Connect HDMI Sources
➊
Connect HDMI Display
➋
Connect DC 5V/1A power supply (optional)
➌
IR Receiver
➍
Power Indicator
➎
Input port LED indicators
➏
Input switch button
➐
cONNEctION AND OPERAtION
1. Connect HDMI input sources first, and then connect HDMI display
2. The switch is powered from HDMI cable. In case the switch
doesn't work normally, please try to connect a 5V@1A power
supply
3. Set the HDMI sources at HDMI output and the HDMI display at
HDMI input mode
4. Switch between 3 inputs manually by "selection" button
6
3x1 HDMI Switch
7
