Oras Vega 1800 Installations- Und Bedieningsanleitung Seite 20

1875U
EN 817
I (ISO 3822) (0.2 l/s) Oras lab.
50 - 1000 kPa
0.26 l/s (300 kPa)
0.2 l/s (300 kPa, with flow reducers)
180 kPa (0.2 l/s)
300 kPa (0.2 l/s, with flow reducers)
max. +80°C
CSTB 348-M1-09/2
1860EX
EN 817
II (ISO 3822) Oras lab.
50 - 1000 kPa
0.27 l/s (300 kPa)
170 kPa (0.2 l/s)
max. +80°C
1871
EN 817
I (ISO 3822) (0.2 l/s)
II (ISO 3822) (0.3 l/s)
50 - 1000 kPa
0.33 l/s (300 kPa)
0.2 l/s (300 kPa, with flow reducers)
260 kPa (0.3 l/s)
160 kPa (0.2 l/s)
300 kPa (0.2 l/s, with flow reducers)
max. +80°C
STF VTT-11362/06
Downloaded from www.Manualslib.com manuals search engine
150±15
G 1/2
150±20
G 1/2
150±3
20
85
95
50
85
