3. Place the two bolts into the two holes (Figure 4.2).
4.
Tighten the bolts with the supplied hex key. The bolt
heads should touch the housing (Figure 4.2).
5. Repeat for the right Legpad.
5

Figures

Figure 2.1
1.
2.
1
3.
4.
5.
6.
2 2 2
3
4
5
Laevo | V2.57 LEGPAD EN | P7
Manual
1x Right Legpad
1x Left Legpad
8x M4 x 16 self-locking
bolts
1x 3mm hex key
(4x bolts + 4x spare
bolts)
