2. Package and Specification

2.1 Package and Assembly
Pos. Order
# Code
12700
2 12701
2 12702
2 12703
2 12704
1 12710
3 12711
4 12712
5 12713
6 12714
7 12715
8 12716
9 10901
10 12717
11 12718
T 12719
2.2 Specification
Parameter
Min. pipe dia.
Max. pipe dia.
Max. working pressure
Air motor max. pressure
Air motor min. capacity
Inlet air motor
Inlet main line
Weight
4
Downloaded from www.Manualslib.com
Model Description
PBT-2 Pipe blasting tool 12" (300mm) – 36" (900mm) Complete package
incl. two leg sets (short leg set 12" – 20" and long leg set 24" — 36"),
2 x PBN-6.5 nozzles, wrenches set
PBN-5.0 Dia. 5.0 mm B4C Blast nozzle for PBT-2 (option)
PBN-6.5 Dia. 6.5 mm B4C Blast nozzle for PBT-2
PBN-8.0 Dia. 8.0 mm B4C Blast nozzle for PBT-2 (option)
PBN-9.5 Dia. 9.5mm B4C Blast nozzle for PBT-2 (option)
Blast head
Legs
Bracket A
Bracket B
Plug
Air motor connection
Nylon protect pipe
CFT-2 CFT-2 Sandblast coupling
Air motor
Gear
Pipe (not included in the package)
manuals search engine
Value
12" (300mm)
36" (900mm)
10 bar
7 bar
0.5 m /min
3
Plug nipple DN 7,2
Sandblast coupling CFT-2
8 kg (in box)
CONTRACOR Version 5.0
®
