Available in two height profiles, ECCO's EB7181 and
EB7186 LED beacons are designed to meet ECE R65
Class I or II Specifications. The EB7181 model features
a 2" height profile and a single row of LEDs while the 3"
tall EB7186 model features two rows of LEDs and is also
available with dual color warning capability.
Specifications include 12-24VDC operation, multiple flash
patterns including simulated rotate and synchronization
capability. This manual provides information about
installation, function, safety, maintenance, replacement
parts and warranty.
Failure to install or use this product according to manufacturer's recommendations may result in property
damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the safety information
contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices
are essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that
s/he can operate the system without losing eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use,
the vehicle operator should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open
trunks or compartment doors), people, vehicles, or other obstructions.
6. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning signal.
Never take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an
intersection, driving against traffic, responding at a high rate of speed, walking on or around traffic lanes.
7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying
all laws regarding warning signal devices. Therefore, the user should check all applicable city, state, and federal laws
and regulations. The manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specifications:
Size
EB7181: 6.5" L x 6.5" W x 2.3" H
EB7186: 6.5" L x 6.5" W x 3.3" H
Weight
EB7181: 1.2 lbs.
EB7186: 1.5 lbs.
Input Voltage: 12-24 VDC
Current Draw
EB7181: 6.2A
EB7186: 8.6A
Installation and Operation Instructions
EB7181 & EB7186 Series LED Beacons
Page 1 of 3
