IMPORTANT!
Read all instructions before installing and using. Installer: This manual must be
delivered to the end user.
!
WARNING!
Failure to install or use this product according to manufacturer's recommendations may result in property
damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the safety
information contained in this manual.
1. Proper installation combined with operator training in the installation, use, care and maintenance of vehicle equipment accessories is
essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this worklamp. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that s/he can
operate the system without losing eye contact with the work area.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use, the
vehicle operator should ensure the projection of the beam is not blocked by vehicle components (i.e., open trunks
or compartment doors), people, vehicles, or other obstructions.
6. The manufacturer assumes no liability for any loss resulting from the use of this device.
SAA
NOTE: Black die cast Aluminum housing gets very hot to touch after operating constantly for several hours.
Specifications:
Voltage: 12-80 VDC
Current: 1.2 Amps @ 12 VDC
Weight: 1.3 lbs.
Lumens: 900 (Raw), 800 (Effective)
Installation and Operation Instructions
WORKLAMPS
Installation:
Place 3/8"-16 X 1" hex screw through bottom hole in mounting
bracket. Place bracket around hole at bottom of worklamp
and align holes. Place 1/4"-20 X 2.5" hex head screw through
bracket holes and worklamp mounting hole. Secure with 1/4"
lock washer and 1/4" hex nut. Use an X-sized drill bit to drill
a 0.397" diameter clearance hole in mounting surface. Place
3/8"-16 x 1" hex head screw in hole and secure with 3/8"-16
lock nut. Adjust worklamp to desired position and tighten both
nuts. Do not exceed 76 in-lbs for the 1/4"-20 assembly. Do
not exceed 276 in-lbs for the 3/8"-16 assembly.
