No. Description
1 ATX 12V Power Connector (ATX12V1)
2 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
3 Clear CMOS Jumper (CLRCMOS1)
4 Chassis Intrusion Header (CI1)
5 ATX Power Connector (ATXPWR1)
6 CPU Fan Connector (CPU_FAN1)
7 USB 2.0 Header (USB10_11)
8 System Panel Header (PANEL1)
9 SATA3 Connector (SATA3_0)
10 SATA3 Connector (SATA3_1)
11 Chassis Fan Connector (CHA_FAN1)
12 TPM Header (TPMS1)
13 Front Panel Audio Header (HD_AUDIO1)
