Lumnia Standard - Instruction Manual
+
Includes Lumnia
Encapsulation Module
This manual is based on the latest information and is provided subject to alteration.
We reserve the right to change the construction and/or configuration of the product
and versions at any time without obligation.
All rights reserved. No part of this document may be reproduced, stored in a database or any other retrieval
system, or published, in any form or way, electronically, mechanically, digitally per photo print or microfilm or
any other way without written permission from the author.
Downloaded from
www.Manualslib.com
manuals search engine
Werbung
Inhaltsverzeichnis
Inhaltszusammenfassung für Rentokil Lumnia Standard
- Seite 1 Lumnia Standard - Instruction Manual Includes Lumnia Encapsulation Module This manual is based on the latest information and is provided subject to alteration. We reserve the right to change the construction and/or configuration of the product and versions at any time without obligation.
- Seite 2 1. Safety Warning The lamps in this unit produce ultraviolet (UV) light, which can cause skin or eye damage if viewed directly for a long period. Only fit the correct type of UV lamps in the unit. The unit shall be installed and serviced by individuals with appropriate qualifications and/ or experience in accordance with national regulations in the country of operation and...
- Seite 3 WARNUNG ADVERTENCIA Die Lampen in diesem Gerät erzeugen Las lámparas de esta unidad producen ultraviolettes (UV)-Licht, das Haut- oder luz ultravioleta (UV), que puede provocar Augenschäden verursachen kann, falls man daños en la piel o en los ojos si se mira für längere Zeit direkt hineinblickt.
- Seite 4 AVERTISSEMENT WAARSCHUWING Les lampes de cet appareil produisent une De lampen in dit toestel produceren lumière ultraviolette (UV) susceptible de ultraviolet (UV) licht, dat huid- of oogschade causer des dommages à la peau ou aux kan veroorzaken indien men gedurende yeux en cas d’exposition prolongée.
- Seite 5 UYARI ADVARSEL Üründeki lambalar ultraviyole (UV) Lampene i denne enheten produserer ışık üretmekte olup, bu türde ışık ultrafiolett (UV-lys) doğrudan uzun süre bakıldığında cilt forårsake skader på hud eller øyne hvis veya gözde hasara yol açabilir. Ürüne du ser på lyset for lenge av gangen. yalnızca doğru türde UV lamba takın.
- Seite 6 AVVERTENZA AVISO As lâmpadas desta unidade produzem Le lampade in questa unità producono luce ultravioletta (UV), che può causare luzes ultravioletas (UV) que podem danni alla pelle o agli occhi se vi si provocar danos oculares ou cutâneos è esposti direttamente per un lungo em caso de incidência direta durante um periodo.
-
Seite 7: Equipment For Installation
2. Introduction The Lumnia Standard unit uses two ultra-violet LED driven lamps that attract flying insects that are then captured on a replaceable glue board or encapsulation module. The modular design of this unit allows for both. The standard product comes as a glue board control device which can be upgraded to a monitoring device by adding the Lumnia + encapsulation module. -
Seite 8: Connecting The Power Source
4. Connecting the Power Source NOTE: Cable Assembly not supplied in box. Ordered direct from Rentokil Initial to meet specifi c country requirements. WARNING: You must NOT connect the unit into a lighting circuit. You must connect the power cable to a standard power socket. -
Seite 9: Positioning The Unit
5. Positioning the Unit Position the unit on a suitable wall at a minimum height of 1.8 metres to the bottom of the unit. Figure 1 illustrates the suggested mounting height and illustrates what happens during service mode. Position the unit as far as possible from sources of ambient light. - Seite 10 For safety reasons, the unit contains a micro switches that disables the UV lamps if you open the Front Louvre or if the products service mode (Slide) is activated. See section 7 and 8. Figure 2 indicates the size and space considerations for louvre cover opening sweeps at 90°.
-
Seite 11: Installation Preparation
7. Installation Preparation 1.8M Ø6mm Downloaded from www.Manualslib.com manuals search engine... - Seite 12 Opening the Louvres Mounting Lumnia NOTE: Remove lamps before screwing See Section 12 for more details on lamp removal SECURE WITH ALL 4X SCREWS Downloaded from www.Manualslib.com manuals search engine...
- Seite 13 8. Activating the Slide Mechanism 9. Preparing the Glue Board Fold Flex Remove Liner Downloaded from www.Manualslib.com manuals search engine...
- Seite 14 10. Installing the Glue Board 11. Removing the Glue Board Downloaded from www.Manualslib.com manuals search engine...
- Seite 15 12. Removing and Replacing the UV - LED Lamps Removing UV - LED Lamps Do not touch LED when servicing, maintaining or cleaning the lamps. NOTE: Ensure the lamp is pushed fi rmly back into the left hand fi tting Replacing UV - LED Lamps Downloaded from www.Manualslib.com...
- Seite 16 13. User Interface Settings Functions for use with Lumnia ONLY: See Section 17 for Lumnia User Interface Mode Button I = Low II = Med III = High A A A C C C A = Adaptive Low* B = Adaptive Med* C = Adaptive High* * Adaptive Mode: The Adaptive light setting reduces the light output when light levels are below...
- Seite 17 14. Lumnia Encapsulation Module Your Lumnia Standard can be turned from a monitoring device to a control device in areas where fl y infestations may occur. A motorised Encapsulation Module can be purchased to use with your Lumnia. Roll included...
- Seite 18 16. Loading Lumnia Encapsulation Downloaded from www.Manualslib.com manuals search engine...
- Seite 19 17. Lumnia Encapsulation Interface Settings See Section 14 for fi tting the Lumnia+ Module The interface is activated when the Module is inserted Lumnia User Interface Glue Roll Manual Override Glue Roll Service Day Setting 30 day setting rolls on a clean glue surface every 24 hours Mode Button See Section 13 for Mode Setting User Interface...
- Seite 20 18. Glue Roll Manual Override GREEN: OPERATIONAL RED: FAULT NOTE: Counter for Lumnia Encapsulation Module resets when removed from Lumnia. Important that module is removed for a new Glue Roll Downloaded from www.Manualslib.com manuals search engine...
- Seite 21 19. Servicing: Replacing the Glue Roll Part Part Part Part Part Reuse parts A - E above to create the new Roll Assemblies below New Roll With emboss Without emboss Part Part Part Part Part Downloaded from www.Manualslib.com manuals search engine...
-
Seite 22: Accessories And Spares
Rentokil can accept no liability whatsoever for any loss or damage arising from the product being serviced maintained or repaired by unauthorised personnel. -
Seite 23: Specification
• Unit including Lamps 5.14 kg & Glueboard • Lumnia+ Encapsulation 1.35 kg (unit) Module Lumnia+ Encapsulation Module 24V DC Refer to Lumnia Standard Manual for full installation instructions, scan the QR code or visit: www.rentokil.com/manuals Downloaded from www.Manualslib.com manuals search engine... - Seite 24 Rentokil reserve the right to alter the specification or design without prior notice. Rentokil cannot accept any liability for any loss or damage arising from the use of any information contained within this manual, or from any incorrect use of the product described herein.
