User's Manual
Multiprotocol receiver compatible with AXESKEY range transmitters. Codifies the transmitter
signal in differents protocols according to its configuration: Clock&Data, Wiegand 26 and
Wiegand 37.
1. TECHNICAL CHARACTERISTICS
Power supply
Frequency
Consumption standby /
operating
Operating temperature
Watertightness
Dimensions
2. INSTALLATION AND CONNECTIONS
Attach the rear part of the chassis to the wall using the plugs and screws supplied. Pass the
cables through the bottom of the receiver. Connect the power cables to the terminals marked
in the mother board, as indicated. Mount the receiver front and pass the cables and the
antenna through it.
3. OPERATING
3.1.
CONFIGURATION AND CONNECTION FOR THE DIFFERENT PROTOCOLS
Protocol
Alimentation
Clock&Data
+ -
Wiegand
+ -
26
Wiegand
+ -
37
* formats configurable with the USERPLUS.
EN
12V dc (9Vdc-21Vdc)
868,35MHz
14mA/36mA
-20ºC to +85ºC
IP54 (with glands IP65)
82x190x40mm
PROTOCOLE
Sortie signal
S=CLOCK and
L=DATA
D0 and D1
D0 and D1
7
PROTOCOLE
SW1
SW2
OFF
ON
ON
OFF
ON
ON
Format
8 BCD digits
4 bits (zeros)+ 20
bits code*
---
1247082/1.0
