Bio-Circle GT Compact Betriebsanleitung Seite 43

Machine
1 Sink
2
Fitting 1/2" external thread
3 Pan head screw
4
Flex faucet
5 3-way valve
6
3-way valve cap and knob, grey
7 Hose clamp size F
8 Flowthrough brush
9 Flowthrough brush hose, length 80 cm
10 Hose clamp size H
11 Hose 12 x 4, lenght 180 cm
12 Loop strap inside diameter 22 mm
13 1/2" hose connector, angeled
14 Drain filter insert kit, plastic
15 Magnet
16 Damper
Washer
Pan head screw, 4,8 x 16 mm
17
Filter bag bracket
18 Sink gasket
19
Sink rod
20 Allen screw, M6x8
21 Connecting bolt short
22 Connecting bolt long
23 Replacement control box BIO-CIRCLE GT
24 Tank
25 Drain cock (clamp screw)
26 Threaded nipple 1"
Order No.
G48202
G484539
G48211
G48D373
G484506
G484531-01
G21726
G20726
G23026
G21826
G28126
G484433
G484540
G48D743
G48D309
G48D310
G48204
G48205
G552040
G48201
G484585
G48210
G48D312
G48D311
G52030
G48206
G48214
G552024
43
EN
D
