SEAT HOOD
The seat is equipped with a hood which is assembled
by inserting its fasteners into special holders located
on both sides of the seat's chassis (Fig. 21). In order
to disassemble the hood, press the buttons (they
are located on its fasteners, on both sides) and then
pull it upwards (Fig. 22).
The position of the hood can be adjusted. To do this
place it in the desired position, moving it forwards
or backwards. The hood is equipped with a
protective apron which is attached to it with a zip
fastener (Fig. 23). The apron also has a practical
pocket (Fig. 24). After disassembling the apron, the
hood must be additionally fastened to the seat's
chassis using the hook and loop fasteners (Fig. 25).
After disassembling, the ventilation mesh is
uncovered (Fig. 26).

BACKREST ADJUSTMENT

The support has 4 regulated positions. You can raise
it up by lifting it up to the desired position (Fig. 27).
To lower the support, you should pull up on the metal
lever (Fig. 28).
ATTENTION! These operations may be difficult if a
child is occupying the seat.

FOOTREST ADJUSTMENT

The footrest is adjusted by pressing the side buttons
simultaneously and placing it in the desired position
(Fig. 29, 30).
BAR
The seat is equipped with a safety bar. It is assembled
by inserting its fasteners into special holders located
on both sides of the seat's chassis (Fig. 31). In order
to disassemble the bar, press the buttons (they are
located on its fasteners, on both sides) and then pull
it towards you (Fig. 32). After assembling the safety
bar, please fasten the seatbelt, which protects the
child against slipping (Fig. 33, 34).
ATTENTION! Always use the bar with the safety
seatbelt if a child is occupying the seat.
HARNESS
The pram is equipped with a 5-point harness. When a
child is sat on the seat, fasten the harness by
pressing its forks into the lock (Fig. 35) and tighten
it. In order to unfasten the seatbelt, press the forks
and pull outside (Fig. 36).
ATTENTION! Always use the harness if a child is
occupying the seat.
SEAT COVER
The seat is equipped with a cover which is assembled
by fastening the press studs on the cover to the
12
press studs located on both sides of the hood (Fig.
37).
BAG
The carriage is equipped with a practical bag. In order
to fasten the bag, put the back handle on the
carrier's grip, and then fasten the snaps on both
sides of the handle (Fig. 41). A practical strap allows
the bag to be carried on a shoulder.
CAR SEAT ASSEMBLY
The pram is also available in a version with a car seat
for children from 0-11 kg. In order to assembly the
car seat, it is necessary to fasten the adapter to the
pram's chassis first. It must be placed into special
holders (two on both sides of the pram). Locking is
automatic.
ATTENTION! Please check whether the adapter is
assembled properly before using the pram (all 4
holders must be locked). After the adapter is
assembled, the car seat can be installed. Its
fasteners must be placed into special plastic holders
located in the adapter (Fig. 44, 45).
ATTENTION! Please check whether the car seat is
properly assembled before using the pram (both
holders must be locked). The car seat is equipped
with a hood and a cover, which are assembled using
press studs (Fig. 46, 47). It is possible to adjust the
position of the handle. Adjustment is done by
pressing the red buttons on both sides of the car
seat and moving the handle to the desired position
(Fig. 49). In order to remove the adapter, pull the
red levers inwards (they are located in the lower
parts of the handles, on both sides of the pram) (Fig.
51) and then pull the adapter upwards.

WARRANTY

1. The manufacturer provides a warranty for the
period of 12 months from the date of the carrier's
purchase, confirmed by the point of sale with a
proof of purchase.
2. The warranty includes damage resulting from
production faults and latent defects.
3. Complaint about the carrier's deficiency should be
made in the point of sale.
4. Removing the deficiencies of the carrier resulting
from the manufacturer's fault will take place within
21 days since its purchase.
5. The warranty does not cover:
- Damage resulting from inappropriate use of the
carrier.
- Tears and other covering fabric damage cause by the
user.
