INSTALLING WITH ISOFIX AND TOP TETHER
Your car seat can be installed using Isofix and a top tether strap.
Pull the red button out, the Isofix connector will come out automatical-
ly. (B-1)
Unlock the Isofix connectors of the car seat by pushing the Isofix point
release button(lS)(B-2).
Open the plastic panel to get the top tether out and close the panel.
(B-3)
Hook the top tether strap on the anchor bracket and fasten the belt
tightly. (B-4)
Place the car seat on the vehicle seat and connect the lsofix connectors
to the vehicle Isofix attachments (B-5). There will be an indicator visible
on the connector.
Attach the Isofix connectors until the Isofix connection indicators (16)
turn from red to green and a click is heard (B-6). This will mean the seat
is locked into position.
Once in place pull the lsofix adjustor button until tight and the car seat
is tight against the vehicle seat back rest.
