2 Connect one end of the power cord to the AC adapter and the
3 Insert the battery pack into any bay on the charger. The charging
4 Charge the battery pack for at least 4 hours.
Understanding the Charging Status LEDs
LED Color
Off
Solid red
Blinking red
Solid green
Input voltage: 13 VDC ±2 V
4
Downloaded from www.Manualslib.com
other end to an AC power outlet.
status light next to the battery turns on after two to three
seconds.
Description
No battery installed in charger.
The battery is charging.
The battery charger is experiencing a charging
error. Remove the battery for 10 minutes and then
reinsert it into the charger. If the charger still shows
an error, the battery may be damaged. Replace the
battery.
The battery is completely charged.
Caution: See Compliance Insert for use restrictions
associated with this product.
manuals search engine
4-bay battery charger
Charging status
light
