GENERAL CONTROLS

5. Platter: This platter must be securely fastened to
the turntable prior to operation. The Motor Drive
Belt can be found on the drive ring underneath
the platter.
6. 45 RPM Adapter Holder: Holds the included 45
RPM adapter.
please place it in this holder.
7. Stop Button: This button stops the turntable
motor.
8. 33 and 45 RPM Buttons: These buttons control the RPM of the turntable platter.
9. Arm Clip: This specially designed arm clip secures the tone arm while at rest or when not
in use. The arm clip has been designed to remain in the up position while unlocked.
10. Raise / Lower Lever – Raises and lowers the tonearm.
Downloaded from www.Manualslib.com
6
8
When not using the adapter,
manuals search engine
5
IMPORTANT
Make sure that the slipmat is always
placed on top of the platter while using
the turntable. Failure to use the slipmat
may cause damage to your media as
well as damage to the turntable.
Remove the plastic cartridge cover
(needle cover) before operating the
turntable.
5
10
9
7
