ENGLISH
ML6 is a LED multivoltage module designed to replace standard
incandescent bulbs inside the flashing lights already installed.
• Multivoltage technology to adapt the module to all types of
flashing lights
• Screw connectors to install the module ML6 on the
attachments E14
• Removable terminal panel to avoid cable torsion during

installation

IMPORTANT WARNING

Warning! The installation of the product has to be made by
qualified personnel, under the laws and rules in force and
following the instructions of this handbook.
It is important to respect the following warnings:
• The device must be installed inside hermetical containers with
protection degree equal or higher than IP44.
ATTENTION: when the device is
connected to the control unit, the board ML6
is energized and must not be touched.
• Before performing electric connections, it is
recommended to turn off the power supply to the
control unit.
• Before performing any manual operation on module
ML6, it is recommended to turn off the power supply
to the control unit.
• Check that the voltage of the product is compatible with the
one on the clamp of the control unit used for the connection
of the flashing light.

TECHNICAL FEATURES

Power supply
Intermittence
Max working cycle
Working temperature
Dimensions
INSTALLATION
1. Turn off the power supply to the control unit.
2. Open the container of the flashing light where module ML6 shall
be installed
3. Unscrew the bulb
4. Screw the module on the flashing light
5. Disconnect the two terminals of the flashing light and connect
them to the two terminals of the module
6. Position jumper J1:
- J1 inserted: flashing controlled by the control unit
- J1 NOT inserted: flashing controlled by the flashing light
7. Hermetically close the flashing light container
NOTE: the purpose of the screw attachment is just to fasten
the module, the supply is provided by the two cables arriving
from the control unit on the removable terminal panel.
24 ÷ 300Vdc
24 ÷ 230Vac 50/60Hz
automatic
80%
-20 ÷ +60 °C
74 x 32 x 30 mm
DISPOSAL
As for the installation, the disposal of the product at the end of
its effective life must be performed by qualified personnel.
This product is made of various types of material, some of
which can be recycled while others must be disposed of.
Enquire about the recycling or disposal systems available for
this product category in compliance with regulations locally in
force.

DECLARATION OF CONFORMITY

V2 S.p.A. hereby declare that ML6 equipment conforms to the
essential requirements established in the directive
2004/108/CEE ELECTROMAGNETIC COMPATIBILITY
2006/95/CEE LOW VOLTAGE DIRECTIVE
Racconigi, 01/04/2012
Legal representative, V2 S.p.A.
Cosimo De Falco
