Einbau | Installation | Pose | Montaggio | Montaje | Montering
SM6-AL CB1
Länge Befestigungswinkel
Length Mounting bracket
Longueur Équerre de fixation
Lunghezza Squadretta
Longitud Ángulo de fijación
Längd Fästvinkel
[mm]
2 Sets/2 sets/2 jeux/
109 - 469
2 kit/2 juegos/2 set
3 Sets/3 sets/3 jeux/
505 - 793
3 kit/3 juegos/3 set
4 Sets/4 sets/4 jeux/
829 - 1009
4 kit/4 juegos/4 set
1
1 AVENTICS | CB1 | R412022745–BDL–001–AA
RTC
25 mm
SW 2
siehe/see/voir/
vedere/véase/se
2
Montageanleitung | Assembly instructions | Mode d'emploi |
Istruzioni di montaggio | Instrucciones de montaje | Monteringsanvisning
Befestigungswinkel für Sensor, Serie SM6-AL
Mounting bracket for SM6-AL series sensors
Equerre de fixation pour capteur, série SM6-AL
Squadretta per sensore, serie SM6-AL
Ángulo de fijación para sensor, serie SM6-AL
Fästvinkel för sensor, serie SM6-AL
CB1
R412022745/01.2015,
Replaces: –, DE/EN/FR/IT/ES/SV
Lieferumfang
Delivery contents
Fourniture
Fornitura
Volumen de suministro
Leveransomfattning
für/For/Pour/
per/para/för RTC ‡ 25 - 32 mm
32 mm 40 mm
4
3
für/For/Pour/
per/para/för RTC ‡ 40 - 50 mm
50 mm
siehe/see/voir/
4
vedere/véase/se
2 Nm
