DMX Protokoll / DMX Protocol
Channel
1
2
3
4
5
Function DMX Value
Play mode 000 – 127
128 – 255
Gobo selection 000 – 255
Horizontal mo- 000 – 063
vement
064 – 127
128 – 191
192 – 255
Centre rotation 000 – 127
128 – 255
Flash speed 000 – 255
Specification
Blackout
Open
20 gobos (000-255) / 13 = 000-19
No effect
Pan rotation
Tilt rotation
Pan & tilt rotation
No rotation
Centre rotation
11 gradual speed (000-255) / 23+1
= 000-011
