R E M O V E T I L T H E A D F R O M O L L I N A R M
I M P O R T A N T
Th ese p arts are n ot req uire d fo r d u al b ar
i nsta l la tion. You m a y c o ns id er retaining
t h em i n c ase Oll in need s to b e re tu rned
t o si n gl e sc reen c onf igu r atio n.
2
H O W D O Y O U W A N T T O C O N F I G U R E
Y O U R M O N I T O R S ?
Co ckp it Co n f igurat io n
Fla t Conf i gur ati on
Go to st ep
Go to s te p
3
9
3
I N S T A L L D U A L B A R T O M O N I T O R A R M
Fit f ixin g
3A
bu sh e s
Ensure that both bushes
are fitted.
Ins ta ll d ual b ar
3B
to arm
Ensure fixing bushes
remain in place during
installation.
Ins ta ll f ixin g screw
3C
I M P O R T A N T
Use fixing screw supplied
with dual bar
i.e. with red cover.
Ins ta ll d ual b ar t o ar m
3D
I M P O R T A N T
Ensure screw is fully
tightened. Red screw cover
should not be visisble.
4
A T T A C H V E S A P L A T E S T O M O N I T O R S
Repeat for second monitor.
2
x
2
x
S crew s ove r-inserted
S crew s under-i nserted
I M P O R T A N T
It is th e resp ons ibi lity o f th e i nstaller to ensu re all mou nti ng
s crews are pro perly engag ed with a mini mu m of 4 x 360 ˚ tu rns
into the di sp lay. Under or o ver insertion may c au se damag e t o
the equ ipment o r inju r y to p ersonnel.
M A X
SCREEN WEIGHT
8KG/17LB
I . E . M A X 4 K G P E R S C R E E N
5
M O U N T M O N I T O R S T O D U A L B A R
I M P O R T A N T
Take care when installing first
monitor as bar will not be balanced.
Ensure mount clicks into place.
6
A D J U S T M O N I T O R A R M T O S U I T W E I G H T
O F M O U N T E D M O N I T O R S
I M P O R T A N T
Correct posit ion
of arm
Arm must be positioned
at maximum height when
adjusting, otherwise
damage may result
N O T E
See Monitor arm instructions for details of adjustment method.
7
P O S I T I O N M O N I T O R S T O S U I T V I E W I N G
P R E F E R E N C E
Posi ti on moni tors
7A
si de- by- si de
Si mply sl ide moni tors
together on dual bar.
Ali gn screens
7B
(i f necesar y)
Us e key supli ed wi th
moni tor arm
Clockwise raises monitor
Anti-clockwise lowers monitor
Level the screens
7C
( i f necess ar y)
Adjust moni tor ti lt
7D
(i f necessar y)
Turn thumbscrew to
tilt monitors.
8
I N S T A L L M O N I T O R C A B L E S I N T O C A B L E
M A N A G E M E N T F E A T U R E S
N O T E
See Monitor arm instructions for details on cable management.
9
T O R E C O N F I G U R E D U A L
O P T I O N A L
B A R F R O M ' C O C K P I T ' T O
' F L A T ' S C R E E N F O R M A T
Cockpi t Conf igurat i on
Fla t Conf i gu rat i on
Usi ng your f i ngert i p, uncli p bot h
9A
end caps and push t hem off
Remove both end caps
9B
Sli de mounts from du al bar
9C
