BESOA Vantor Montageanleitung Seite 6

EN
6
INDIVIDUAL PARTS AND ASSEMBLY
1 Check that all parts are present.
2 Place the table top (A) upside down on a soft surface so that it is not
scratched.
3 Make a note of the nameplate on each leg (B) and then place the leg in the
appropriate labelled area on the underside of the tabletop (A) as shown
above.
4 Align the pre-drilled holes in the legs (B) with the pre-drilled holes on the
underside of the tabletop (A).
5 First slide the washers (E) onto the Allen screws (D). Then insert the Allen
screws (D) through the holes in the table top (A) and tighten them lightly
by hand. Fasten the cross strut with the 2 screws and nuts. Then tighten
the screws (D) with the supplied Allen wrench (E). Tighten the screws until
the legs (B) are tight, but do not tighten them too tightly.
Table top (x1)
Table legs (x2)
Cross strut (x1)
Allen screws (x12)
Washers (x12)
Nuts & bolts for the cross
strut (x2)
Allen key (x1)
Spanner (x1)
