TRAK-IT TOOL MODEL C3, C3 ST
CAUTION — THE TRAK-IT TOOL SHOULD NOT BE USED IN THE RAIN OR WHERE
EXCESSIVE MOISTURE IS PRESENT. THESE CONDITIONS MAY RESULT IN DAMAGE
TO TOOL COMPONENTS AND CAUSE THE TOOL TO MALFUNCTION.
Trak-It Tool Operation
WARNING
The Trak-It tool has been designed to be used as a hand-operated tool. Never attempt to
operate the tool by fixing it to a stationary work surface or object. Operating the tool in a
fixtured position may cause uncontrolled pin discharge and result in injury to the operator
or bystanders.
PRESS CONTACT ARM AGAINST WORK SURFACE.
Fan Motor will turn on. Fuel is injected into the Combustion Chamber and mixed with air
by the Fan.
SQUEEZE THE TRIGGER
The Spark Plug sparks and the fuel/air mixture ignites. Combustion powers the Piston
Assembly, which in turn drives the fastener.
RELEASE TRIGGER - LIFT THE TOOL
The Combustion Chamber opens. Fan exhausts hot gases and cools internal
components.
15
NOTE: IF NO ADDITIONAL CYCLES ARE MADE, FAN WILL RUN FOR 8 SECONDS AND
THEN SHUT OFF.
WARNING
THE CONTACT ARM AND NOSE MAY BECOME HOT AFTER PROLONGED OR RAPID
USE.
