Webr@cer 851
2.3 MODEM LED'S
• When the ADSL line is connected the Link status LED will indicate the ADSL link.
--> Flashing: The modem is linking with the ADSL network.
--> ON:
• The Traffic LED will flash when there is data traffic in progress.
CHAPTER 3: DRIVER INSTALLATION ON WINDOWS
98/ME/2000/XP
• Insert the installation CD in your PC. The setup screen will appear automatically.
If the Autorun does not start automatically, please double-click the Autorun Icon on the CD.
15/7/02 8:53 am
PSTN
Modem
The link is established. Now the modem is ready to make an Internet
connection.
! Do not connect the USB cable to the modem yet !
Page 5
Traffic LED
Link status
