User Manual S5

Attaching and Removing the Belt Clip

To Install:
Install belt clip onto the belt clip holder located on the upper part of the battery, held whilst
looking at the back of the unit. Locate the slot on the battery and push belt clip downward until a
click is heard.
To Remove:
Push and hold the release button located at the top of the belt clip and slide the clip off the belt
clip holder.

Attaching and Removing the Jack Cover

To attach accessory socket cover screw as per below drawing, in the case of using an optional
audio accessory unscrew cover using a screwdriver, fit accessory and fully tighten locating pin.
Page 9
