Geräteanschlüsse
1.1.
Frontplatte
Cat5 Connection 1
Power
Die Anschlüsse „Cat5 Connection 2" sind nur in der 64-Kanal Version (ADX-64) verfügbar.
1.2.
Rückseite
ADAT Connections 5-8
Cat5 cable: only one (A or B) plugged
5
1 2 3 4 5 6 7 8
Cat5 cable:
both (A and B)
1 2 3 4 5 6 7 8
plugged
Input
Output
Die Anschlüsse „ADAT Connections 5-8" sind nur in der 64-Kanal Version (ADX-64) verfügbar.
A
B
ADX-32/64
6
7
8
32/64 channel ADAT multicore extender
Type 1003
Made in Switzerland
www.appsys.ch
Serial Number:
Input
Output
Input
Output
Input
Output
ADAT® is a registered
Trademark of Alesis Corp.
Cat5 Connection 2
Power
Application Systems
ADAT Connections 1-4
Cat5 cable: only one (A or B) plugged
1 2 3 4 5 6 7 8
Cat5 cable:
both (A and B)
1 2 3 4 5 6 7 8
plugged
ADX-32/64
32/64-channel ADAT® multicore extender
Type 1003
Made in Switzerland
www.appsys.ch
A
B
ADAT is a registered trademark of Alesis Corp.
1
2
3
Input
Output
Input
Output
Input
Output
Input
Application Systems
Power input
4
8..24V DC
5W
Ø2.5/5.5mm
Output
