Satellite Search
1.
Make sure all connections are made as shown on page 5.
2.
Turn on the TV and satellite receiver if not integrated.
3.
Press POWER on the VuQube II Power Inserter
The Power Insterter LED will pulsate orange while powering up (this will take about 10 seconds).
Pulsing orange
When ready to scan the LED will flash green.
This colour flashing is indicating that Astra 2 is selected if you wish to change see page 6 for details
Green
Off
Press and immediately release the power inserter button to start a scan.
The LED will flash quickly green during the scan. The antenna unit may lock onto the satellite in as little as
2 minutes, nut may occasionaly take up to 10-15 minutes.
Green
Green
Off
When scan is complete and the satellite is found, the LED will turn solid green.
Watch TV!
If the satellite is not found the LED will turn solid dim orange.
Dim Orange
Verify all connections are properly made and that the receiver is on. Check for line of sight
obstructions, and if need be, move the antenna to have a better view of the southern sky.
!
Press the button to start a new scan.
Power down
After a period of inactivity, the VuQube II will enter standby mode. You will know the system is in standby mode
as the light turns dim orange. The system will continue to function in standby mode.
To exit standby mode, the button must be pressed. You will know the system has now exited standby mode as
the light will come on.
Note: You will not need to rescan your VuQube II on exiting standby mode unless the antenna has been moved.
08
Green
Off
Green
Off
Off
Green
Green
Off
