RF-SMOKE DETECTOR CC-70
Thank you for purchasing our smoke alarm. Please take a few minutes to read
the user's manual thoroughly and familiarize yourself and your family with its
operation. And save it for future reference.
Product Specifications
POWER
DC9V Alkaline or Carbon Zinc battery
OPERATION CURRENT
< 10uA (standby), < 30mA (alarm)
ALARM VOLUME
> 85dB(A) at 3 meters
ALARM SENSITIVITY
0.14-0.20dB/m
Wireless base
EN146 4:2
5
Net alarm LED
Description
The unit is a photoelectric 9V DC smoke alarm. It is operated by 9v battery
(6LR61 or 6F22), battery life 1 year minimum. With the photoelectric technology,
it is more sensitive to detecting slow smolder fires which general thick, black
smoke, little heat and may smolder for hours before bursting into flames. The
smoke alarm do not contain the radioactive material which is harmless to the
environment.
The smoke alarm should be installed in every room (except the bathroom), and
every other area of the home, making sure the people in the home will be able to
hear and respond to the alarm sound. For minimum protection you should fit an
alarm in the hallway between the living areas and sleeping areas. Place the unit
near to the living areas as possible and ensure the alarm is audible when the
bedrooms are occupied.
Typical single storey dwelling with recommended
Install a smoke alarm on the ceiling or wall inside each bedroom and in the
hallway outside each separate sleeping area. If a bedroom area hallway is more
than 30 feet long, install a smoke alarm at each end. If there is a basement:
install a smoke alarm on the basement ceiling at the bottom of the stairwell.
Typical multi-storey dwelling with recommended protection
Install a smoke alarm on the ceiling of wall inside each bedroom and in the hall-
way outside each separate sleeping area. If a bedroom area hallway is more than
30 feet long, install a smoke alarm at each end install a smoke alarm at the top
of a first-to-second floor stairwell.
Important Safety Information
1. The test button accurately tests smoke alarm functions. Do not use any other
test method. Test smoke alarm weekly to ensure proper operation.
2. Do not remove or disconnect battery. This will take out your protection. Open
windows or fan the air around smoke alarm for silence it.
3. This smoke alarm should be installed only by a licensed, qualified electrician.
Observe and follow all local and national electrical and building codes for
installation.
4. This smoke alarm is designed to be used inside a single family only. In
multifamily buildings, each individual living unit should have its own smoke
alarms. Do not install in non-residential buildings. And this smoke alarm is
not a substitute for a complete alarm system.
5. Install a smoke alarm in every room and on every level of the home. Smoke
may not reach the smoke alarm for many reasons. For example, if a fire starts
in a remote part of the home, on another level, in a chimney, wall, roof, or on
the other side of a closed door, smoke may not reach the smoke alarm in
time to alert household members. A smoke alarm will not promptly detect a
fire except in the area or room in which it is installed.
6. Smoke alarm may not alert every household member every time. The alarm
horn is loud in order to alert individuals to a potential danger. However, there
may be some circumstances where a household member may not hear the
alarm (i.e. outdoor or indoor noise, sound sleepers, drug or alcohol usage, the
hard of hearing, etc.). If you suspect that this smoke alarm may not alert a
household member, install and maintain specialty smoke alarms. Household
member must hear the alarm's warning sound and quickly respond to it to
reduce the risk of damage, injury, or death that may result from fire, If a house-
hold member is hard of hearing, install special smoke alarms with lights or
vibrating devices to alert occupants.
7. Smoke alarms can only sound their alarms when they detect smoke or detect
combustion particles in the air. They do not sense heat, flame, or gas. This
smoke alarm is designed to give audible warning of a developing fire.
However, many fires are fast - burning, explosive, or intentional, and others
are caused by carelessness or safety hazards. In this circs, Smoke may not
remake the unit alarm QUICKLY ENOUGH to ensure safe escape.
8. Smoke alarms have limitations. This smoke alarm is not foolproof and is
not warranted to protect lives or property from fire. Smoke alarms are not a
substitute for insurance. Homeowners and renters should insure their lives
and property. In addition, it is possible for the smoke alarm to fail at any time.
For this reason, you must test the smoke alarm weekly and replace unit every
5 years.
Status LED indicates send
or learn wireless code
Send / Learn button
Batterie-Spezifikation
RATING VOLTAGE
DC 9V (Alkaline or Carbon Zinc battery)
PACKAGE
6F22 for carbon zinc
or 6LR61 for alkaline battery
Replace Battery
1. Turn the alarm body counterclockwise and take out the alarm body from the
bracket, then pull out the signal plug.
2. Remove the bracket, take out the two low batteries, install the two new
batteries to battery box.
3. Fit the bracket on the wireless base and plug in the signalplug, then turn the
alarm body clockwise to fix the alarm body.
4.Test smoke alarm using test button. The sound pattern is 3 short beeps-
1.5 seconds pause, repeat it. If there's no sound output, it means that the
smoke alarm is faulty or the installing operation is wrong, and you should gain
the correctly method of disposal through reading "TROUBLE SHOOTING".
During testing, may the other smoke detector will alarm. Once release the
button, others will stop alarming in 1 minute.
Do Not Install Smoke Alarms in the Following Places
1. Near appliances or areas where normal combustion Regularly occurs
(kitchens, near furnaces, hot water heaters). Use specialized smoke alarm
with unwanted alarm control for this areas.
2. In areas with high humidity, like bathrooms or areas near dishwashers or
washing machines. Install al least 10feet away from these areas.
3. Near air returns or heating and cooling supply vents. Install at least 3 feet
away from these areas. The air could blow smoke away from the detector,
interrupting its alarm.
4. In rooms where temperatures may fall below 40℉ or rise above 100℉.
5. In extremely dusty, dirty, or insect – infested areas influence particles interfere
with smoke alarm operation.
Testing the Smoke Alarm
Test each smoke alarm to be sure it is installed correctly and operating properly.
1. Do not use an open flame to test the alarm. You may ignite and damage the
alarm or your home.
2. Test the alarms weekly and upon return from vacation or when no one has
been at home for several days.
3. Stand at an arm's length from the unit when testing. Test all smoke alarms
weekly by doing the following step.
4. Firmly press the test button for at least 5 seconds. The alarm will sound
3 short beeps – 1.5 seconds pause, then repeat it until release the button.
The alarm may sound for up to a few seconds after releasing the test button.
DANGER: If the alarm sounds, and it is not being tested, it means the unit is
sensing smoke, THE SOUND OF THE ALARM REQUIRES YOUR IMMEDIATE
ATTENTION AND ACTION.
Wireless base description
1. Learn mode
Please take one alarm, press the Send / Learn button for 3 second, the status
LED will ON for 30 seconds, then release the send/learn button. It indicates it
is running into learn mode. We call this alarm as Alarm A.
2. Send mode
Please take another alarm, press the Send / Learn button until status LED is
ON, release the button immediately, the status LED will flash for 30 seconds,
it indicates it is running into send mode. Hereinafter we call this alarm as
Alarm B.
3. When Alarm B is in the send mode, for alarm A, if the status LED flash for
2 times, It indicates the learning code is finished.
4. After learning is finished, If Alarm B is alarming, it will send wireless signal,
Alarm A will alarming within 1 minutes.
5. Follow step 1, 2, 3, You can operate all the other alarms.
6. If the smoke alarm is sound, and the NET alarm LED is flash, it indicates
the other smoke alarm is alarming. Please check which one is alarming and
ensure this area is safe.
Poles for fix the bracket
Wireless frequency (optional)
433MHz or 315 MHz
Operation current:
< 10uA (standby),
< 15mA (monitor or net alarm)
Wireless distance
> 30 meters
INSTRUCTION MANUAL
Signal plug
DC 9V batteries
