Solstice Comfort – 15.09.2010
8.3

Armrests

8.3.1 Armrests – Adjusting the height
1 × Allen key (4 mm)
1. Loosen clamping screw (A).
2. Slide the armrest pad to the desired height.
3. Retighten the clamping screw.
Caution!
Do not pull out armrests beyond the mark indicating the
maximum pull-out height.
8.3.2 Armrests – Adjusting the position
1 × Allen key (4 mm)
A
1. Loosen clamping screw (A).
2. Slide the armrest pad to the desired position.
3. Retighten the clamping screw
8.4
8.4.1
A
1. Loosen clamping lever (A).
2. Slide the headrest to the desired height.
3. Retighten the clamping lever.
8.4.2
1. Loosen clamping lever (B).
2. Set the head gap.
3. Retighten the clamping screw.
8.4.3
The angle of the headrest can be adjusted stepless by the
ball joint (C).

Headrest

Headrest – Adjusting the height
Headrest – Adjusting the head gap
Headrest – Adjusting the angle
C
GB – 9
A
B
