No. Description
1
ATX 12V Power Connector (ATX12V1)
2
Power Fan Connector (PWR_FAN1)
3
CPU Fan Connector (CPU_FAN1)
4
CPU Fan Connector (CPU_FAN2)
5
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6
ATX Power Connector (ATXPWR1)
7
USB 3.0 Header (USB3_2_3)
8
SATA3 Connectors (SATA_7)
9
SATA3 Connectors (SATA_8)
10 Chassis Fan Connector (CHA_FAN1)
11
Clear CMOS Jumper (CLRCMOS1)
12
Chassis Speaker Header (SPEAKER1)
13
System Panel Header (PANEL1)
14
SATA3 Connectors (SATA_6)
15
SATA3 Connectors (SATA_5)
16 SATA3 Connectors (SATA_4)
17
SATA3 Connectors (SATA_3)
18
SATA3 Connectors (SATA_1)
19
SATA3 Connectors (SATA_2)
20 USB 2.0 Header (USB45)
21 USB 2.0 Header (USB67)
22 TPM Header (TPMS1)
23 Print Port Header (LPT1)
24 Front Panel Audio Header (HD_AUDIO1)
25 PCIe Power Connector (PCIE_PWR1)
26 Chassis Fan Connector (CHA_FAN2)
27 USB Power Jumper (USB01_PWR1)
2
