Danfoss VLT 5000 Serie Instruction Seite 8

PIN PIN PIN PIN PIN
MK1 MK1 MK1 MK1 MK1
1 +24, must be connected to terminal 12/13 on control card
2 GND24, must be connected to terminal 20 on control card
3 B, encoder output signal must be connected to terminal 32 on control card
4 A, encoder output signal must be connected to terminal 33 on control card
5 5V input for ready signal from encoder
6 Ready relay output,
7 Ready relay output,
8 Not used
9 Input for external 24V supply, max current consumption is 200 mA.
10 Ground for external 24V supply.
Explanation to MK1 Pin 9 and 10
If the 5 V TTL-encoder has a current consumption
under 150 mA the Pin 9 can be connected to Pin 1
and Pin 10 to Pin 2 of MK1.
If the current consumption is over 150 mA, an
external 24 V DC-supply must be connected to Pin 9
and 10.
PIN PIN PIN
PIN PIN
MK2 MK2 MK2 MK2 MK2
1 5V DC-output, supply for encoder (max current is 300mA)
2 Ground for 5V encoder supply
3 Encoder input, A-signal
4 Encoder input, A-signal
5 Encoder input, B (90°) signal
6 Encoder input, B (90°) signal
7 Encoder input, Z (zero pulse) signal
8 Encoder input, Z (zero pulse) signal
PIN PIN
PIN PIN PIN
MK3 MK3 MK3
MK3 MK3
1 Not used
2 Ground
3 Encoder output, A signal
4 Encoder output, A-signal
5 Encoder output, B signal (90°)
6 Encoder output, B-signal (90°)
7 Encoder output, Z signal
8 Encoder output, Z-signal
8
VLT ® Series 5000 5V TTL -> 24V DC Option
Description Description Description Description Description
max 1A, 24 VDC
max 0,5A 120 VAC
Please note: The maximum curr Please note: The maximum curr Please note: The maximum curr Please note: The maximum curr Please note: The maximum current of the
terminals 12/13 of the VL terminals 12/13 of the VL terminals 12/13 of the VL terminals 12/13 of the VLT 5000 contr terminals 12/13 of the VL
not exceed 200 mA. not exceed 200 mA.
not exceed 200 mA. not exceed 200 mA. not exceed 200 mA.
Description Description Description
Description Description
Description Description
Description Description Description
5V TTL / Linedriver, RS 422
Load: Min.120 Ω
MI.50.I1.51- VLT is a registered Danfoss trademark
