INDICE Funcionamiento ................4 Activación del lector de tarjetas ........5 Dar de alta tarjetas personales......... 6 Dar de baja tarjetas personales ........6 Ajustar tiempo de apertura de puerta ........ 7 Ajustar tiempo de puerta abierta ........7 Esquema de cableado ..............8 Características Técnicas ..............
FUNCIONAMIENTO El Módulo PRIVATE BRUTO es capaz de controlar hasta 400 tarjetas. Cada una de éstas tarjetas, que funcionan sin ningún tipo de mantenimiento, está dotada de un código electrónico único en el mundo (no existen dos tarjetas con el mismo código). Una vez dadas de alta, podrá...
Activación del lector de tarjetas Para activar el lector es preciso programar la tarjeta MASTER. Esta es la tarjeta que servirá, posteriormente, para acceder a las funciones de programa- ción. El resto de funciones del KIT serán operativas aunque no esté activado el lector de tarjetas.
Dar de alta tarjetas personales Es posible dar de alta hasta un total de 400 tarjetas, siguiendo éstos pasos. ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! 1. Presentar la tarjeta 2. Presentar una tras otra todas las tarje- 3. Presentar nuevamente la MASTER.
Ajustar el tiempo de apertura de puerta Este parámetro, ajustable entre 1 y 99, representa el tiempo en segundos, que permanecerá activado el abrepuertas tras la presentación de una tarjeta dada de alta. ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! 1.
ESQUEMA DE CABLEADO 220 Vac CONTROLADOR AUTONOMO DE PROXIMIDAD 12 V ac/dc PRIM 220V SEC. 12Vac C NA NC ALIMENTADOR 12 Vac/Vdc 1.5 A PULSADOR SALIDA ABREPUERTAS (opcional) 12 Vac/Vdc 0.5 A DETECTOR PUERTA ABIERTA (opcional) Conexiones del Lector: Pulsador de salida (Bs, -): Permite abrir la puerta con la misma temporización que la programada para el acceso (1 a 99 seg).
TABLA DE USUARIOS Es muy importante rellenar la tabla de usuarios, con el nombre de usuario y el código de tarjeta entregada a dicho usuario. Necesitará saber estos datos si desea dar de baja una tarjeta sin tenerla fisicamente, por ejemplo por que se haya perdido. Para gestionar el sistema sin tener las tarjetas fisicamente necesitará...
Seite 11
INDEX Operation ................. 12 Activation of card reader ..........13 Activation of personal cards ......... 14 Deactivation of personal cards ........14 Door opening time adjustment ........15 Adjusting open door time ..........15 Wiring Diagram ................ 16 Technical features ..............16 Users Table ................
OPERATION The ANTIVANDAL PRIVATE Module is able to control up to 400 cards. Each of these cards, which function with no need for any type of maintenance, comes with an electronic code unique in the world (there are no two cards with the same number).
Activation of card reader To activate the reader the MASTER card must be programmed. This is the card that will serve, later, to access to the preogramming functions. The other KIT functions will be operative even though the card reader is not activated. The system will take as MASTER card the first one shown to it after the power has been switched on.
Activation of personal cards A total of up to 400 cards may be activated, following these steps: Beep! Beep! Beep! Beep! Beep! Beep! Beep! 1. Show the MASTER Show the cards to be activated 3. Show the MASTER card card. The indicators one at a time.
Door opening time adjustment This parameter, adjustable between 1 and 99, represents the time in seconds that the door release remains activated after an activated card has been shown. Beep! Beep! Beep! Beep! Beep! Beep Beep! 1. Show the MASTER card 2.
WIRING DIAGRAM 220 Vac PROXIMITY CONTROLLER 12 V ac/dc PRIM 220V SEC. 12Vac C NA NC POWER SUPPLY 12 Vac/Vdc 1.5 A EXIT BUTTON ELECTRIC LOCK (optional) 12 Vac/Vdc 0.5 A OPENED DOOR SENSOR (optional) Reader connections: Door opening pushbutton (Bs, -): Required to open the door with the same timing adjustment which has been programmed in the access (1 to 99 sec.).
USERS TABLE Is very important to fill the users table, with the user name and the card code delivered to this user. It will be neccesary to know this data to delete a card without having it physically, for example if the card has lost. To manage the system without having the cards physically it will neccessary a Proximity Programming Keypad Ref.
Seite 19
INDEX Fonctionnement ..............20 Activation du lecteur de cartes ........21 Enregistrer des cartes d'accès........22 Annulation des cartes d'accès ........22 Réglage du temps d'activation de la gâche électrique ..23 Réglage du temps d'ouverture de la porte ...... 23 Schéma de câblage ..............
FONCTIONNEMENT Le module BRUTO est capable de contrôler jusqu'à 400 cartes. Chacune des cartes, qui fonctionne sans maintenance, est dotée d'un code électronique unique au monde (il n'existe pas deux cartes avec le même code). Une fois enregistrées, vous pouvez les utiliser pour l'ouverture de la porte d'ac- cès à...
Activation du lecteur de cartes Pour activer le lecteur il est nécessaire programmer la carte MAÎTRE. Cette carte va nous servir, postérieurement, pour enregistrer le reste des cartes per- sonnelles d'accès. Les autres fonctions du KIT sont opérationnelles même si le lecteur de cartes n'est pas activé.
Enregistrer des cartes d'accès Il est possible d'enregistrer jusqu'à 400 cartes, en suivants ces étapes: ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! 3. Présentez à nouveau la 1. Présentez la carte 2. Présentez une à une toutes les cartes carte MAÎTRE pour ter- MAÎTRE.
Réglage du temps d'activation de la gâche électrique Ce paramètre, qui peut être réglé de 1 à 99, représente le temps d'activation de la gâche électrique, en secondes, aprés presentation d'une carte enregistrée. ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! ¡Bip! 2.
SCHÉMA DE CÂBLAGE 220 Vac CONTRÔLEUR AUTONOME DE PROXIMITÉ 12 V ac/dc PRIM 220V SEC. 12Vac C NA NC ALIMENTATION 12 Vac/Vdc 1.5 A POUSSOIR SORTIE GÂCHE ELECTRIQUE (en option) 12 Vac/Vdc 0.5 A DÉTECTEUR PORTE OUVERTURE (en option) Connexions du Lecteur: Poussoir de sortie (Bs, -) : permet l’ouverture de la porte, avec la même temporisation que celle programmée pour l’accès (1 à...
TABLEAU D’USAGERS Il est très important de remplir le tableau d' usagers, avec le nom de l’usager et le code de la carte qui lui est remise. Vous aurez besoin de ces données et si vous voulez annuler une carte sans en disposer matériellement, par exemple dans le cas d’une carte perdue.
NÄHERUNGS-KARTENLESEGERÄT Das Brutomodul-PRIVATE kann bis zu 400 Karten kontrollieren kann. Jede dieser Karten, die völlig wartungsfrei sind, ist mit einer weltweitig einzigartigen elektronischen Kennung versehen (es gibt keine Karten, die die gleiche Kennung aufweisen). Nach deren Registrierung können Sie sie für die Öffnung der Türe des zu überwachenden Zugangs einsetzen.
Aktivierung des Kartenlesegeräts Zur Aktivierung des Lesegeräts ist es erforderlich, die MASTER-Karte zu programmieren. Das ist die Karte, die die es danach ermöglicht, auf die Programmierfunktionen zuzugreifen. Die übrigen Funktionen des KITS sind betriebsbereit, auch wenn das Kartenlesegerät nicht eingeschaltet ist. Die Anlage betrachtet jene Karte als MASTER-Karte, die ihr als erste vorgelegt wird, nachdem die Anlage unter Strom gesetzt wurde.
Registrierung von Id.-Karten Gemäß den folgenden Schritten können bis zu 400 Karten registriert werden. Beep! Beep! Beep! Beep! Beep! Beep! Beep! 1. Die MASTER-Karte 2. Nacheinander alle Karten vorlegen, die 3. Zum Abschluss erneut vorlegen. registriert werden sollen. MASTER-Karte L e u c h t a n z e i g e n vorlegen, zeigt den Status Leuchtanzeigen den...
Einstellung der Türöffneraktivierungszeit Dieser Parameter, der zwischen 1 und 99 eingestellt werden kann, bezeichnet die Zeit in Sekunden, die der Türöffner nach Vorlage einer registrierten Karte aktiviert bleibt. Beep! Beep! Beep! Beep! Beep! Beep Beep! 1. Die MASTER-Karte 3.Zum Abschluss erneut 2.
SCHALTPLÄNE 220 Vac Autonomes Annäherungszutrittskontrol 12 V ac/dc PRIM 220V SEC. 12Vac C NA NC NETZGERÄT 12 Vac/Vdc 1.5 A Drucktaster für Ausgang (optional) Türöffner 12 Vac/Vdc 0.5 A Detektor geöffneter Tür (opti o nal ) Lektoranschaltungen: Drücktaster für Ausgang (Bs,-): Es erlaubt die Tür während 1 bis 99 Sek öffen lassen, so lange wie es für den Eintritt programmiert ist.
BENUTZERSTABELLE Es ist sehr wichtig die Benutzerstabelle mit dem Name und der Code der Benutzer auszufüllen. Sie werden diese Daten brauchen, wenn Sie eine Karte abmelden müssen und Sie es nicht haben, z.B. beim Verlorengehen. In diesem Fall, brauchen Sie einen Näherungsprogrammierungstastatur Ref. 2306. Es wäre auch möglich das System durch das PC mit dem Programm Winprox Ref.
