T&S B-2360-SERIE Installations- Und Wartungsanleitungen

Bubbler faucet

Werbung

Verfügbare Sprachen

Verfügbare Sprachen

Limited One Year Warranty
T&S warrants to the original purchaser (other
than for purposes of resale) that such product is
free from defects in material and workmanship
for a period of one (1) year from the date of pur-
chase. During this one-year warranty period, if
the product is found to be defective, T&S shall,
at its options, repair and/or replace it. To obtain
warranty service, products must be returned to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other trans-
portation charges of the product to T&S and the
return of repaired or replaced product to the
purchaser are the responsibility of the purchaser.
Repair and/or replacement shall be made within
a reasonable time after receipt by T&S of the
returned product. This warranty does not cover
Items which have received secondary finishing
or have been altered or modified after purchase,
or for defects caused by physical abuse to or
misuse of the product, or shipment of the prod-
ucts.
Any express warranty not provided herein,
and any remedy for Breach of Contract which
might arise, is hereby excluded and disclaimed.
Any implied warranties of merchantability or fit-
ness for a particular purpose are limited to one
year in duration. Under no circumstances shall
T&S be liable for loss of use or any special con-
sequential costs, expenses or damages.
Some states do not allow limitations on how
long and implied warranty lasts or the exclusion
or limitation of incidental or consequential dam-
ages, so the above limitations or exclusions may
not apply to you. Specific rights under this war-
ranty and other rights vary from state to state.
P/N: 098-009779-45 Rev.4
Date: 09-07-04
Drawn: TEH
Checked: MVW 09-08-04
Approved: MVW 09-08-04
Installation and
Maintenance
Instructions
BUBBLER FAUCET
B-2360-SERIES
Deutsch:
Installations- und
Wartungsanleitungen
Español:
la Instalación y las
Instrucciones de
Mantenimiento
Français:
les Instructions
d'Installation et
d'Entretien

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für T&S B-2360-SERIE

  • Seite 1 Installation and Maintenance Instructions Limited One Year Warranty T&S warrants to the original purchaser (other than for purposes of resale) that such product is free from defects in material and workmanship for a period of one (1) year from the date of pur- chase.
  • Seite 2: Exploded View

    Exploded View * Some items are listed for instructional purposes and may not be sold as separate parts.
  • Seite 3 Part Number Guide Bubbler Assembly Body Faucet Shank Washer, Rosette 001000-45 Washer 000999-45 Locknut 002954-45 Nut, Coupling 000958-20 Adjustment Screw, Flow Control 012697-45 Seal, Stem Bottom 012596-45 Spout, Bubbler 012680-40 Flow Straightener 009594-45 Holder, Spout Guard 009596-40 Screw, Spout Guard 009598-45 Spout Guard, Flex 009595-45...
  • Seite 4: General Instructions

    General Instructions Installation: 1. Turn off water supply and drain lines. Drill a hole approximately 7/8” (22mm) diameter in sink or countertop where you are installing no.1. 2. Loosen no.6 with a wrench and remove no.6, no.5, no.4, and no.3 from threaded end of no.2.
  • Seite 5: Instrucciones Generales

    Instrucciones Generales Instalación: 1. Cierre la fuente de agua y desagüe las tuberías. Perfore un hueco de aproximadamente 7/8” (22mm) de diámetro a través del lavatorio o el mostrador donde la parte No.1 será instalada. 2. Con una llave afloje y remueva las partes No.6, No.5, No.4, y No.3 del lado con rosca de la parte No.2.
  • Seite 6: Instructions Générales

    Instructions Générales L’Installation: 1. Fermer la réserve de l’eau et égoutter la tuyauterie. Percer un trous avec un diamètre de 7/8 pouce (22mm) dans le comptoir ou l’évier où vous aller installer Nº.1. 2. Deserrer Nº.6 avec une clef anglaise et enlever Nº.6, Nº.5, Nº.4 et Nº.3 de l’extrémité...
  • Seite 7: Allgemeine Anleitungen

    Allgemeine Anleitungen Installation: 1. Wasser absperren und Wasser aus der Leitung abfliesen lassen. An der gewünschten Stelle eine Bohrung von 22 mm Durchmesser vornehmen. 2. Mit Hilfe eines Schraubenschlüssel Nr. 6 lösen und Nr. 6, Nr.5, Nr. 4 und Nr. 3 von dem Gewindeende von Nr.
  • Seite 8 T&S BRASS AND BRONZE WORKS, INC. A firm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O. Box 1088, T & S Brass-Europe Travelers Rest, SC 29690 ‘De Veenhoeve’ Phone: (864) 834-4102 Oude Nieuwveenseweg 84 Fax: (864) 834-3518 2441 CW Nieuwveen tsbrass@tsbrass.com E-mail: The Netherlands...
