1. BEFORE USING THIS DVR

1.1 Package Content

¾ 16CH / 8CH Model
… DVR
… IR Remote Controller
… IR Receiver Extension Cable
… Adapter & Power cord
… 25 Pin DSUB Connector
¾ 4CH Model
… DVR
… IR Remote Controller (For Selected Models Only)
… CD Manual

1.2 Front Panel

1) LED Indicators
HDD is reading or recording.
An alarm is triggered.
Timer recording is on.
Under playback status.
DVR is powered on.
( ) / ( ) /  ( ) /  ( )
2)
Press / /
In the playback mode:
Press " " to pause playback.
Press " " to stop playback.
Press "" to fast forward.
Press "" to fast rewind.
3) MENU
Press "MENU" to enter the main menu.
4) ENTER
Press "ENTER" to confirm the setting.
5) LIST (Event List Search)
Press to quickly search the recorded files by four event lists: RECORD LIST / MOTION
LIST / ALARM LIST / TIME LIST, or select FULL LIST to show all the event logs.
To quickly search the time you want, select "QUICK SEARCH". Set the time range you
want, and select "Start" to play the recorded video clip during the specified time.
/ to move up / down / left / right.
1
BEFORE USING THIS DVR
… HDD screws
… Manual for IR Remote Controller
… CD Manual
… USB Mouse
… HDD screws
… Manual for IR Remote Controller
… Adapter & Power cord
