APPENDIX

Notebook Specifications

Processor Intel ® Centrino
Intel Dothan Processor 725 ~ 770
(Intel Dothan Processor 1.6GHz to 2.26GHz)
Intel Celeron M processor 350~390
(Intel Celeron M processor 1.30G to 1.70G)
uFC-PGA Package
400/533MHz FSB
BIOS 512K BB Flash ROM
Chipset Intel 915GM+ ICH6-M
Main Memory Zero on board and two SO-DIMM memory sockets
256MB to maximum 2GB 400/533MHz DDR2 SDRAM
LCD Display 14.1" TFT-LCD XGA, 1024x768
14"W TFT-LCD XGA,1280x768
Graphics Intel 915GM Integrated graphics controller
Intel GMA 900 Technology, support Direct
External Display Modes VGA 640x480, 256/64K/16.7M colors
SVGA 800x600, 256/64K/16.7M colors
XGA 1024x768, 256/64K/16.7M colors
SXGA 1280x1024, 256/64K/16.7M colors
Hard Disk Drive One 2.5" 9.5mm IDE HDD 4200/5400rpm with
Ultra DMA/100/133 support
Supported capacities of 40/60/80/100 GB
Floppy Disk Drive N/A
Optical Disk Drive One modularized 5.25"/12.7mm optical storage
device, choices of
24/10/8/24X Combo CD-RW+DVD (factory option)
8/4/8X DVD Dual RW Double Layer(factory option)
Modem & Bluetooth 56K S/W MDC Modem ,V.90/92 support
Bluetooth: USB Interface(factory option)
LAN & WLAN Ethernet 10/100BaseT on board
Embedded dual band antenna for WLAN(option)
Intel PRO/Wireless 2200BG, IEEE 802.11b+g
®
Intel ® PRO/Wireless 2915ABG, IEEE 802.11a+b+g
Interface I/O Port 1 IEEE 1394
1 Card Bus Type II
2 Audio jacks: Microphone-in/Headphone out
1 VGA port/Mini D-sub 15-pin for external monitor
4 USB ports (v2.0)
1 RJ11 connector for Modem
1 RJ45 connector for Ethernet
1 DC-in
Audio Built-in AC'97 stereo sound, with 3D sound effects
Built-in two stereo speakers
Memory Card Reader Support Memory Stick, MS PRO, Multi Media
Card, Secure Digital
Mini-PCI One Mini-PCI Slot, Type 3A
22
TM Mobile Technology System Status LED
Keyboard
Button Hot Keys
on Keyboard
® 9.0
Power Management
Battery Pack & Life
AC adapter
Pointing Device
Dimensions/Weight
Security
OS & S/W
Power on/Suspend, Battery Charging, HDD Access,
RF, Caps Lock, Scroll lock and Number Lock
86-key US/87-key EU/88-key JP with Windows
function keys
1 power button
1 AP1 button
2 QSB buttons: Email, Internet
Function Keys
Fn+F1 Suspend switch
Fn+F2 Wireless Enable/Disable
Fn+F3 LCD/CRT/LCD+CRT Switch
Fn+F4 Brightness down
Fn+F5 Brightness up
Fn+F6 Mute
Fn+F7 Volume Down
Fn+F8 Volume Up
Fn+F9 Media Play/Pause
Fn+F10 Media Stop
Fn+F11 Media Play Backward
Fn+F12 Media Play Forward
Fn+Esc Blue Tooth Enable/Disable
Full feature ACPI power management, Stand-by,
Suspend to Disk, Suspend to RAM
ACPI 2.0 supported with Intel SpeedStep
Li-Ion 6 cells, 2200mAh/per cell battery pack
Battery life up to 3.5 hrs (in Windows XP)
Output: 19V DC, 3.42A, 65W
Input: 100~240V AC, 50/60Hz Universal
3 pin AC plug
Built-in touch pad.
2 click buttons
Dimensions: 325(W)x244(D)x23~29(H)mm
Weight: 2.2 Kg (with 6 cell battery, ODD)
Kensington lock hole
Windows XP compliance
