TC 180 - CLEANING-SANITIZING INSTRUCTIONS
1 Unloose and remove the holding screws
4 Unplug the drive motor connections...
7 Lift up drive motor and bracket assembly
10 Remove bin vane
Pay attention to the slot when place
13
again bin bottom
2 Remove top panel
5 Unloose the top bracket holding screws
8 Remove spout plastic cover
11 Remove bin bottom
Pay attention to match drive motor
14 shaft with bin vane shaft pin when
place again the drive motor assy
3 Unplug the ice level control connection
6 Remove the bin cover holding screws
9 Lift up and remove bin cover
12 Clean/sanitize inside storage bin
