Moeller DILM C 7 M C 15 Serie Montageanweisung Seite 2

12/07 BL2100-8884
Beilage zu ... Complemento a ...
Supplement to ... Приложение к
Additif à ...
Supplemento all' ...
DILM(C)7...M(C)15..., DILMP20, DILA(C)...
DILA-XHI(C)...
Hilfsschalterbaustein
Auxiliary contact module
DILA-XHI...-S
Module de contacts auxiliaires
Modulo contatti ausiliari
Módulo de contactos auxiliares
Модуль вспомогательных
выключателей
Montage
a aufsetzen
Assembly
b rasten
Montage
a place in position
Montaggio
b latch in
Montaje
a mettre en place
Монтаж
b encliqueter
Demontage
c schieben
Disassembly
d abziehen
Démontage
c push
Smontaggio
d remove
Desmontaje
c pousser
Демонтаж
d retirer
