Rear panel controls and connectors

Analogue audio
Connect to 3.5mm
input of any audio
product, or to
analogue inputs on
an amplifier, receiver,
TV or monitor
8
R
Digital coaxial out
L
Line out Digital optical out
Digital optical out
Connect to digital
optical (S/PDIF)
input on an amplifier
or receiver
Digital coaxial out
Connect to digital coaxial (S/PDIF)
input on an amplifier or receiver
Jongo
A2
5.5V DC
USB
USB connector
for optional USB
Ethernet adapter
Mains
adapter
Connect to
mains power
supply
