INSTALLATION AND
ADJUSTMENT MANUAL
M000255
K530-001-6 SMS Presence Mobile Speed
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
Werbung
Inhaltsverzeichnis
Verwandte Anleitungen für SMS K530-001-6
Inhaltszusammenfassung für SMS K530-001-6
- Seite 1 INSTALLATION AND ADJUSTMENT MANUAL M000255 K530-001-6 SMS Presence Mobile Speed DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje FR Manuel d’installation et de réglage NL Handboek voor installatie en instellingen...
- Seite 2 Advertencia Avertissement El montaje del producto no es responsabilidad de SMS Smart Media Solutions AB y es muy Le montage doit impérativement être effectué de façon correcte et ne relève pas de la importante que el producto sea montado correctamente. El montaje incorrecto puede responsabilité...
- Seite 3 Sulla ricevuta devono essere chiaramente leggibili nome be clearly legible on the receipt. The owner is to pay the cost of returning the product to SMS, while del fornitore e data d’acquisto. Le spese di spedizione a SMS sono a carico dell’acquirente;...
-
Seite 4: You Will Need
4 SMS PRESENCE MOBILE SPEED ASSEMBLY INSTRUCTIONS YOU WILL NEED No. 13 No.4 No.5 No.6 NOT INCLUDED 40 kg. to 80 kg. max Display (1x) NUMBER OF PERSONS REQUIRED... -
Seite 5: List Of Parts
SMS PRESENCE MOBILE SPEED 5 LIST OF PARTS (1x) (4x) (4x) (1x) (1x) [M6x16] (2x) Front bottom [M8x16] (4x) (1x) Rear bottom (3x) - Seite 6 6 SMS PRESENCE MOBILE SPEED LIST OF PARTS (cont.) [M8x16] (4x) (1x) (2x) (2x) [M8x10] SCREW KIT (4x) K1 SCREW KIT Screw M6x10 SCREW LIST Screw M6x16 Screw M6x30 Wheel pin Screw M8x20 Screw M6x16 Screw M8x30 Screw M8x16 Screw M8x40...
-
Seite 7: Mount Wheels
SMS PRESENCE MOBILE SPEED 7 Mount wheels 17mm A2 (4x) A3 (4x) (4x) A3 (4x) A4 (4x) - Seite 8 8 SMS PRESENCE MOBILE SPEED Mount main frame to stand B5 (4x) B5 [M8x16] (4x)
- Seite 9 SMS PRESENCE MOBILE SPEED 9 Remove top front cover Unhook Pull Pull Top front cover: Attach cable hook OUTSIDE INSIDE Cable hook B6 (3x)
-
Seite 10: Leave Enough Slack In Cable For Height Adjustment
10 SMS PRESENCE MOBILE SPEED Guide cables through cable hooks Mount top front cover after guiding cable Top front cover: inside view INSIDE Leave enough slack in cable for height adjustment... - Seite 11 SMS PRESENCE MOBILE SPEED 11 C2 (4x) (4x) [M8x16]...
- Seite 12 12 SMS PRESENCE MOBILE SPEED Mount brackets on display (optional) SCREW KIT Mount display on stand...
- Seite 13 SMS PRESENCE MOBILE SPEED Lock and Secure Pull Tighten Secure...
- Seite 14 14 SMS PRESENCE MOBILE SPEED Remove upper back cover upper back cover Mount handles E2 (4x) (4x) [M8x10]...
- Seite 15 SMS PRESENCE MOBILE SPEED Adjust spring tension to balance the weight of the display Procedure to adjust spring tension Loosen screw Loosen screw Repeat process till both springs are approx. at same height and display is balanced...
- Seite 16 16 SMS PRESENCE MOBILE SPEED Mount upper back cover Upper back cover Mount bottom front cover Bottom front cover B4 [M6x16] (2x)
- Seite 17 SMS PRESENCE MOBILE SPEED Mount lower back cover PUSH! TO OPEN PUSH! Use this space to store cables, codecs, accessories, etc. PUSH! TO CLOSE PUSH!
- Seite 18 18 SMS PRESENCE MOBILE SPEED Adjustment & Alignment Adjust! Adjustment screws...
-
Seite 19: Product Dimensions
200 - max 800 Stroke appr 400 mm 5,91 26,40 27,93 709,3 44,15 1121 34,03 23,99 609,3 35,83 All dimensions in mm. Dimensions in [brackets] are in inches. SMS Smart Media Solutions AB Hästholmsvägen 32, 5th floor, SE-131 30 Nacka, Sweden www.smartmediasolutions.se...
