2．Technology Feature
（1）
Control Mode: Remote control and DMX control（1 channel)
（2）
Smoke fluid volume:
（3） ：
Warm up time
（4） ：
Smoke output
（5） ：
Output distance
（6） ：
A p p e a ra n c e
（7）
P r o t e c t i o n G ra d e
Technology Parameter
1．Voltage： AC 200-230 V， 50 HZ/AC 110 -120 V ,60 Hz
(AC 240V,50Hz optional )、 （AC127V，60Hz optional）
2．Po wer： 1500W
3．Fuse: 10A /15A
368×295×357mm
Packing Size :
4.
5． G/W： 5.9Kg

Installation

1．
Fill the Skytec smoke oil:
First loosen the cap of smoke oil can, take out the smoke oil tube. Then
filling, drive tight the cap to avoid the oil leak out. You can also take out the oil bottle, then fill the smoke
oil, make sure the safety of the operator.
1. The power must be disconnected
2.
In order to avoid the short circuit, please don't let the smoke oil flow into the inner part of the smoke
machine
2．Connection of Power and Wire
The ex clusive plug should be used between the connection of fog machine and power, and
please confirm if the rated voltage and frequency is accordance with the power s upply. Every
fog machine with a independent power switch is s uggested, it wi ll be convenient for you to
turn ON or OFF every fog machi ne. Input Voltage and Frequency：
2.5
L
9min
15000cu.ft/min
8M
Use the metal case , streamline design.
：
IP22
fill the smoke oil into the oil bottle. After
Warning
before filling the smoke oil.
