Hybrid Giant Handbuch Seite 12

EnergyPak (rear rack)
∙ Connect the charger to the EnergyPak outlet
on the front of the rear rack.
∙ Connect the charger to an AC outlet.
∙ Charging operation can be discontinued at any
given time.
∙ Disconnect the charger first from the outlet
and then from the charge port.
∙ The bike is ready for usage.
Charging Method 2 - outside the bike
EnergyPak (integrated)
Removing the EnergyPak. (Key Lock Type)
∙ Support the weight of the battery.
∙ Insert the key and unlock the EnergyPak.
(For top loading integrated batteries only: Lift
out the EnergyPak and continue with charging
the EnergyPak.)
∙ Push the anti-drop protection lever to fully
unlock the EnergyPak.
∙ Pull the battery out of the bike.
Removing the EnergyPak (Torx lock type).
∙ Support the weight of the battery.
∙ Insert the Torx tool size 25 and turn counter-
clockwise to release the EnergyPak. The
screw is endless so it will not come out.
∙ Push the anti-drop protection lever to fully
release the EnergyPak.
∙ Pull the battery out of the bike.
1
2
T25
2
1
3
3
9
