MIXER/PRE SECTION
Mic Input Sensitivity
Mic Input Impedance
Line Input Sensitivity
Line Input Impedance
Instrument Input Sensitivity
Instrument Input Impedance
Gain
Ch 1-2 Equalizer
Ch 3-4 Equalizer
Display Leds
Connectors
THD §
Crosstalk §
Mix output voltage gain §
Aux output voltage gain §
Phones output voltage gain §
C/Room output voltage gain §
Max output §
§= measure @ 1KHz
PROTEUS MUSICIAN 400
TECHNICAL SPECIFICATIONS
-50 dB
2KOhms (Balanced)
1KOhms (Unbalanced)
0 dB
20KOhms (Balanced)
10KOhms (Unbalanced)
-35 dB
1 MegOhms (Unbalanced)
40 dB
Semiparametric ±15dB @ 150Hz to 2KHz, fixed Q
High ±15dB @ 20KHz
Low ±15dB @ 20Hz
High ±15dB @ 12KHz
Mid ±15dB @ 1.2KHz
Low ±15dB @ 70Hz
ON/OFF;
High, Low Comp;
Ch. Peak;
Phantom
Mic/Line Input: Female XLR/Jack(Combo) by NEU-
TRIKTM;
Instrument Input: Stereo Jack;
Phones, Aux Outpu
<0.001%
-85dB
49dB
47dB
51dB
39dB
22dBu
