Package content
1x IB-TS301-5, 1x USB 3.0 cable, 1x power cable, 2x 3,5 mm audio cable,
5x protection cap, 1x quick installation guide, 1x socket wrench
Verpackungsinhalt:
1x IB-TS301-5, 1x USB 3.0 Kabel, 1x Stromkabel, 2x 3,5 mm Audiokabel,
5x Schutzkappe, 1x Schnellinstallationsanleitung, 1x Inbusschlüssel
Key features
• Made of high-grade aluminum
• Desk clamp up to 40 mm
• Cable bushing
• 5 units with 3x EU socket, USB-HUB, card reader and audio
• Cable length of 1,6 meter
• Caps to cover the units
Hauptmerkmale
• Aus hochwertigem Aluminium gefertigt
• Tischklemme bis zu 40 mm
• Kabeldurchführung
• 5 Einheiten – 3x EU Steckdose, USB-Hub, Kartenleser und Audio
• Kabellänge von 1,6 Metern
Quick Installation Gudie THC-14
• Schutzkappen für alle 5 Einheiten
Manual IB-TS301-5
Overview/Überblick
1.
1.
3x EU socket 230 V / 3x EU Steckdose 230 V
2. 1x Cable bushing / Kabeldurchführung
3. 2x USB 3.0 Type-A
4. Card reader SD / microSD 3.0 (Multi-LUN)
Quick Wiring Diagram
5. 2x 3,5 mm jack / klinke
(Audio green, MIC red)
(Audio Grün, MIC Rot)
6. USB 3.0 Type-C
™
PC
Notebook
Installation/Installation
• To attach the table socket to the table, unscrew the screws until the
bracket fits around the table top.
Quick Installation Gudie THC-14
• Now tighten the screws so that the table socket strip is firmly atta-
ched to the table top.
• Then connect the power cable as well as the USB and audio cable
and connect them to your host computer.
• The table socket is now ready to use.
• Um die Tischsteckdosenleiste am Tisch zu befestigen, drehen Sie die
Schrauben so weit auf, dass die Bügel um die Tischplatte passen.
• Schrauben Sie nun die Schrauben fest, sodass die Tischsteckdosen-
leiste fest an der Tischplatte befestigt ist.
• Schließen sie nun das Stromkabel sowie USB und Audiokabel an
2.
3.
5.
6.
und verbinden Sie diese mit Ihrem Hostcomputer.
• Die Leiste ist nun Einsatzbereit
4.
© Copyright 2019 by RaidSonic Technology GmbH. All Rights Reserved
The information contained in this manual is believed to be accurate and reliable. RaidSonic Technology
GmbH assumes no responsibility for any errors contained in this manual. RaidSonic Technology GmbH
reserves the right to make changes in the specifications and/or design of the above mentioned product
without prior notice. The diagrams contained in this manual may also not fully represent the product that
you are using and are there for illustration purposes only. RaidSonic Technology GmbH assumes no re-
sponsibility for any differences between the product mentioned in this manual and the product you may
have. Apple and macOS, MAC, iTunes and Macintosh are registered trademarks of Apple Computer Inc.
Microsoft, Windows and the Windows logo are registered trademarks of Microsoft Corporation.
PC
For more information, please visit www.icybox.de.
