About Your Player
To get the most out of your player, also read the comprehensive User's Guide
on your Installation and Applications CD.
Refer to the figure on the cover and match the numbers with those below to
learn more about your player.
1 Power switch
2 Power LED
3 Lock
Push toward the Lock icon
lock the player and prevent
functions from being accidentally
activated.
4 Headphone jack
5 Vertical Touch Pad
See "Using the Navigation Controls"
on page 2.
6 Microphone
7 Play/Pause button
8 Next/Fast Forward button
Press to go to the next track or
menu option.
Press and hold to move forward
within a track.
9 Options button
Press to display more options.
10 Dock connector
Connect the USB synchronization
adapter to this connector.
to
11 Reset hole
See "How do I reset ZEN Vision:M?"
on page 12.
12 Menu/Back button
Press to return to the previous
screen or menu.
Press and hold to return to the main
menu.
13 Previous/Rewind button
Press to go to the previous track or
menu option.
Press and hold to move back within
a track.
14 My Shortcut button
15 Liquid Crystal Display (LCD)
About Your Player 1
