nedis FSBS120GY Kurzanleitung Seite 6

1. Hold the power button A 2 for 2 seconds to switch on the
product.
2. Plug the audio cable B 2 into the audio port B 5 to connect the
product to your media device.
Specifications
Product
Article number
Dimensions (l x w x h)
Weight
Channels
RMS audio output
Peak audio output
Sensitivity
Bluetooth frequency range
Bluetooth® version
Transmission distance
Maximum transmission power
Maximum antenna gain
Battery type
Battery capacity
Charging input power
Charging time
Playback / talk time
Driver unit
Impedance
Frequency response
Declaration of Conformity
We, Nedis B.V. declare as manufacturer that the product FSBS120GY
from our brand Nedis
to all relevant CE standards and regulations and that all tests have
been passed successfully. This includes, but is not limited to the RED
2014/53/EU regulation.
BS120GY_MAN_COMP_1019_print_(19706 1422)_v1.0.indd 6
Bluetooth® speaker
FSBS120GY
121 x 150 x 107 mm
738 g
Stereo via TWS
2 x 5 W
2 x 15 W
85 dB
2402 - 2480 MHz
V5.0 + EDR
10 m
2 dBm
1 dBi
Lithium-ion (18650)
1200 mAh
5 V / 1 A
± 3 hours
Up to 4 hours
Ø 52 mm
4 Ω
100 Hz - 16 KHz
, produced in China, has been tested according
®
