1) Check the oil level that must always be higher than the rod notch both in
the motor and in the pump. As concerns the motor, please refer to
Honda manual.
4) Connect the water supply hose (the inner diameter must be not smaller
than 14 mm) to the pump inlet fitting (A). Make sure that the suction filter of
the suction fitting is always clean. The dirty filter causes a bad water supply
and consequently a very bad pump operation with the inevitable risk of a
rapid wearing out and breakage of the internal mechanisms.
Preliminary operations before starting to use the machine: connect the machine to the water tap
and the electrical socket, then open the water tap and let the water flush out from the high pressure
hose for a few minutes to eliminate water impurities which could block the nozzle. Close water tap,
connect gun and lance and start to work.

INSTALLATION

C
B
B
A
2) Check that the tank is properly filled
with gasoline.
3) Connect the high pressure hose to the
outlet fitting (B), tightening the ferrule
completely and the other end to the
automatic gun (C).
KB2000
A
