2. The Conceptronic 2-Ports Pocket USB-KVM Switch explained
Nr Description
1. USB keyboard connection
2. Monitor (VGA) connection
3. USB mouse connection
4. Speaker (SPK) output connection
5. Microphone (MIC) input connection
6. Connection cables for your PC's (With VGA, USB, SPK and MIC connector)
7. Indication LED PC-1
8. PC selection switch (PC 1 ~ 2)
9. Indication LED PC-2
9
1 2 3
8 7
8
6
5
4
